Engineered for high-performance solar modules, Jwatt’s Modular Type Junction Box series delivers superior electrical efficiency, safety & reliability under all environmental conditions.
This female modular variant ensures secure mating with male connectors, providing stable electrical contact and resistance to environmental stress. Ideal for scalable and modular PV installations.
Flame Retardant
Amps Carrying Capacity Up to 35 Amps
Waterproof Up to IP68
Less Potting Glue
| Box Material | PPE/PA |
| Rated Voltage | 1500 VDC |
| Rated Current | 25 / 30 / 35 Amps (Chip Type) |
| Test Voltage | 8kv (50Hz, Imin) |
| Contact Resistance | ≤ 0.25 mΩ |
| Contact Material | Copper + Tin |
| Degree Protection | IP68 (in Potting) |
| Connection of bus ribbons | Solder |
| Safety Degree | ll |
| Flame Class | UL94-V0 |
| Diode Number | Each 1PC |
| Ambient Temp Range | -40°C...+85°C(IEC) |
| Suitable Cable Cross Sections | 2.5 / 4.0 /6 sq.mm |
| Upper Limiting Temperature | 110°C |
| Ribbon size | Max.8(W)*0.2-0.5(T)mm |
